Your Professional Insole Auxiliary Equipt Supplier!
ZHONG SHAN PING LIAN MACHINERY CO.,LTD. Founded in 1999. In 2006, we began to produce cold and hot forming machinery and equipment, as well as apply for the right to import and export. We are a professional shoe machine manufacturer that integrates product development, design, manufacture, sales, and servicing. Our products include Hot press machine, cold press machine, carbon assembly machine, EVA foaming machine , oven, cutting machine, transfer machine, slicer cutting , inclined machine, laminate machine, mold assembly machine, insole molds etc.
-
![Automatic Insole Logo Transfer Machine]()
Automatic Insole Logo Transfer Machine
Add to Inquiry -
![Insole Logo Transfer Machine]()
Add to Inquiry -
![Pad Printing Machine]()
Add to Inquiry -
![5HP Chiller]()
Add to Inquiry
Why Choose Us
Professional Certifications
We hold High-Tech Enterprise certification and numerous patents. Our products are CE and SGS certified, ensuring international competitiveness.
Production Equipment
We are equipped with advanced production equipment, including overhead cranes, shearing machines, grinders, drilling rigs, saws, CNC machining centers, press brakes, CNC cutting machines, and CNC lathes; this ensures manufacturing precision and efficiency.
Professional Team
We have a professional team of over 200 senior engineers and technicians with extensive experience in production and management, enabling us to design, develop, and manufacture specialized equipment for our customers.
Customization Services
We offer personalized customization services tailored to your needs. The main components of the company's products are made of imported high-quality materials and are equipped with a complete after-sales service system to ensure customer satisfaction.
Our Best-Selling Insole Auxiliary Equipt
Our Company Has More Products to Offer, Please Browse the Product Categories on the Website, If You Have Any Needs, Please Contact Us.
Automatic Insole Logo Transfer Machine
Automatic printing machine is a combination of pneumatic electronic control of automatic heat transfer models. In the case of changing the mold , can be used for transfer printing ,branding , embossing and other areas of the label , the production of high standard pattern.
Insole Logo Transfer Machine
Double head insole identification transfer machine is applicable to roll transfer film and traditional ordinary transfer paper. It can be used for monochrome, two-color and multi-color high-temperature transfer film. It needs to be manually aligned, positioned under the mold, and transferred after the temperature is setting.
Pad Printing Machine
The pad printing machine is used for printing small logos, with high speed, simple operation, easy learning and high production capacity. Mold and ink replacement are very convenient, fast and easy to clean. The weight of the machine is light and the position can be moved at any time.
Automatic Insole Logo Transfer Machine Specification
|
Model |
PL-9013 Pad printing machine |
|
Power |
1KW |
|
Voltage |
220V/380V |
|
Machine dimension L*W*H |
43*33*50mm |
|
Packing dimension L*W*H |
48*38*55mm |
|
Weight ( KG ) |
N:120 / G:130 |
Automatic insole logo transfer machine is widely used in label hot pressing of nature leather, artificial leather, plastic products, glass products,wood, paper and other materials.
Automatic insole logo transfer machine using pneumatic automation principle, the equipment can accurately control, the hot stamping time, the print surface can be fine-tuned ,high-precision design can save the use of alumite, and the greatest degree of adaptation for variable product specifications, suitable for all kinds label heating stamping.
Components of Automatic Insole Logo Transfer Machine
Vacuum holding fixture
Because the insole is very light, vacuum needs to be added to the fixture. During printing, hold the insole to avoid movement, ensure the printing effect.
01
Auto loading system
Positioning the printing station can ensure that the printed insoles are all in the same position.
02
Servo shuttle loading system
Machine with 2 sets of feeding racks, able to prepare insoles in advance for fast printing.
03
Auto unloding device
After printing, the auto unloading system will pick up 1 pairs insoles at once and place them on the drying conveyor belt.
04
Printing station
The front, back, left, and right of printing mesh frame can be individually controlled.
05
Pad Printing Machine Specification
|
Model |
PL-9013 Pad printing machine |
|
Power |
1KW |
|
Voltage |
220V/380V |
|
Machine dimension L*W*H |
43*33*50mm |
|
Packing dimension L*W*H |
48*38*55mm |
|
Weight ( KG ) |
N:120 / G:130 |
Benefits of Pad Printing Machine
Ability to Print on Complex Surfaces
One of the biggest advantages of pad printing is its ability to print on non-flat, irregular surfaces with high precision. The use of a flexible silicone pad allows the machine to conform to shapes such as curved, angled, concave, convex, and even textured surfaces. Whether the surface is cylindrical, spherical, or uneven, pad printing delivers consistent and accurate results.
High Precision and Detail
Pad printing machines are capable of reproducing very fine details, such as thin lines, small text, intricate patterns, and detailed logos. This level of accuracy is achieved through the precise etching of the printing plate (cliche) and the pad's ability to pick up and transfer ink cleanly.
Wide Range of Compatible Materials
Pad printing offers a great balance between setup costs and production efficiency, especially for medium to large production volumes. Polymer plates are affordable and easy to produce, making them perfect for short or custom runs. For high-volume manufacturing, steel cliches provide long-lasting durability, supporting thousands of print cycles without loss of quality. The machine's relatively low maintenance and quick changeover time also contribute to reduced production costs and downtime.
Cost-Effectiveness for Medium to Large Runs
Correct inks ensure colors do not lose their intensity and accuracy during repeated prints. Consistency is imperative for keeping brand identity and producing professional, high-quality work, whether on promotional products, packaging, or industrial goods.
Variety of Ink Types
Pad printing supports a wide selection of ink formulations to meet different performance and finish requirements. Options include solvent-based inks, which offer strong adhesion and durability; UV-curable inks, which provide fast drying and environmental resistance; and epoxy-based inks for special applications like printing on metals or glass.
Types of Pad Printing Machine
Manual pad printing machines are the simplest and most cost-effective option, making them suitable for startups, workshops, and small businesses. These machines are hand-operated and generally used for printing single-color designs on items like pens, lighters, toys, and small promotional products.
Semi-automatic machines combine manual product placement with automated printing cycles. They are faster and more reliable than manual models, producing consistent results while still being affordable compared to fully automated systems. Available in both motorized and pneumatic versions, semi-automatic machines are ideal for medium-scale production. They offer better accuracy, controlled ink distribution, and can handle larger batch sizes without compromising on print quality.
Fully automatic pad printing machines are designed for high-volume production where speed, efficiency, and precision are crucial. These machines require minimal human intervention since product loading, printing, and sometimes even unloading are fully automated. They can handle multiple colors with precise alignment and are often integrated with conveyor belts, robotic arms, or indexing systems.
For complex designs that require multiple colors, multicolor pad printing machines are the best choice. These machines ensure accurate registration of each color, producing high-quality, detailed prints. Some models also come with rotary indexers, allowing 360-degree printing on cylindrical or curved objects like bottles, pipes, or golf balls.
A pad printing machine is a specialized printing equipment that transfers 2D graphics to 3D objects with precision and clarity. It employs an indirect offset printing method in which ink is transferred from an etched printing plate (known as a cliche) to a soft silicone pad, which subsequently pushes the image onto the surface of the object. This approach is particularly beneficial for printing on uneven, curved, or textured surfaces, where traditional printing methods fail.
Pad printing machines are widely utilized in several industries, including electronics, medical devices, automobiles, toys, and promotional products. They can print precise features like logos, symbols, and small text on a variety of materials such as plastic, metal, glass, and ceramic.
Customized Service
In order to better meet the diverse needs of different industries and customers, we can customize insole auxiliary equipt professional solutions according to your specific application scenarios and special requirements. If you need further information or support, please feel free to contact us.
Our Services
All our equipment is customizable.
1
>>
Before production begins, we'll provide a blueprint quote for the CFM model you need.
2
>>
We'll also show you photos and videos of the production process.
3
>>
Finally, we'll provide free accessories after delivery.
4
>>
We guarantee one year of free repairs and a lifetime warranty.
5
Packaging and Shipping
|
Packaging |
PE film, pallet |
|
Transportation methods |
Road transport, rail transport, sea transport, air transport |
Video
Our Certificate
FAQ
As one of the most professional insole auxiliary equipt manufacturers in China, we're featured by quality products and good service. If you're going to buy insole auxiliary equipt in stock, welcome to get pricelist from our factory. Also, customized service is available.
Insole Logo Transfer Machine, Pad Printing Machine, Automatic Insole Logo Transfer Machine
